Vertical multistage centrifugal pump

CDL / CDLF

Light vertical multistage centrifugal pumps, CDL / CDLF

Compact in-line, non-self-priming vertical multistage pumps for clean, thin liquids. CDL has a cast-iron pump head and base; CDLF is the all-stainless-steel version for cleaner or more demanding duties. Stage count sets the head, so one size covers a wide pressure range from the same footprint.

  • Wide size range from 1 m³/h to 200 m³/h rated flow
  • Hot-water type available (up to +120 °C)
  • Standard IP55 / insulation class F two-pole motor
  • Oval flange, ferrule joint or pipe thread on smaller sizes; DIN flange on all sizes
View 478 models Find a pump
CDL / CDLFCNP-S-000004
Flow
0.4–240 m³/h
Head
up to 305 m
Power
0.37–110 kW
Mains
50 Hz / 60 Hz
Models
478
Liquid temp.
-15 to +70 °C (normal type); hot-water type -15 to +120 °C

Sizes

SizeDescriptionRated flowFlow rangeMax pressureMotorConnectionModels
CDL1 / CDLF1 Light vertical multistage centrifugal pump 1 m³/h 0.4–2 m³/h 21 bar 0.37–2.2 kW DN25 40
CDL2 / CDLF2 Light vertical multistage centrifugal pump 2 m³/h 1–3.5 m³/h 23 bar 0.37–3 kW DN25 24
CDL3 / CDLF3 Light vertical multistage centrifugal pump 3 m³/h 1.2–4 m³/h 22 bar 0.37–3 kW DN25 41
CDL4 / CDLF4 Light vertical multistage centrifugal pump 4 m³/h 1.5–7 m³/h 21 bar 0.37–4 kW DN32 24
CDL8 / CDLF8 Light vertical multistage centrifugal pump 8 m³/h 5–12 m³/h 21 bar 0.75–7.5 kW DN40 23
CDL10 / CDLF10 Light vertical multistage centrifugal pump 10 m³/h 5–13 m³/h 22 bar 0.75–7.5 kW DN40 30
CDL12 / CDLF12 Light vertical multistage centrifugal pump 12 m³/h 7–16 m³/h 22 bar 1.5–11 kW DN50 24
CDL15 / CDLF15 Light vertical multistage centrifugal pump 15 m³/h 8–22 m³/h 22 bar 1.1–15 kW DN50 24
CDL20 / CDLF20 Light vertical multistage centrifugal pump 20 m³/h 10–28 m³/h 23 bar 1.1–18.5 kW DN50 21
CDL32 / CDLF32 Light vertical multistage centrifugal pump 32 m³/h 16–40 m³/h 29 bar 1.5–30 kW DN65 51
CDL42 / CDLF42 Light vertical multistage centrifugal pump 42 m³/h 25–55 m³/h 30 bar 3–45 kW DN80 39
CDL65 / CDLF65 Light vertical multistage centrifugal pump 65 m³/h 30–80 m³/h 22 bar 4–45 kW DN100 31
CDL85 / CDLF85 Light vertical multistage centrifugal pump 85 m³/h 50–110 m³/h 17 bar 5.5–45 kW DN100 21
CDL120 / CDLF120 Light vertical multistage centrifugal pump 120 m³/h 60–150 m³/h 16 bar 11–75 kW DN125 31
CDL150 / CDLF150 Light vertical multistage centrifugal pump 150 m³/h 80–180 m³/h 16 bar 11–75 kW DN125 26
CDL200 / CDLF200 Light vertical multistage centrifugal pump 200 m³/h 100–240 m³/h 16 bar 18.5–110 kW DN150 28

Models

Filter by duty point, mains frequency or size. Click a model for its performance curve and data.

Model table (PDF)
ModelSizeStagesHzMotor kWFlow m³/hHead mrpmkg
CDL1-2CDLF1-2 CDL1250 0.37 0.4–2 9–13 290023 CurvePDF
CDL1-3CDLF1-3 CDL1350 0.37 0.4–2 12–19 290023 CurvePDF
CDL1-4CDLF1-4 CDL1450 0.37 0.4–2 16–24 290024 CurvePDF
CDL1-5CDLF1-5 CDL1550 0.37 0.4–2 20–30 290024 CurvePDF
CDL1-6CDLF1-6 CDL1650 0.37 0.4–2 23–36 290025 CurvePDF
CDL1-7CDLF1-7 CDL1750 0.37 0.4–2 27–42 290025 CurvePDF
CDL1-8CDLF1-8 CDL1850 0.55 0.4–2 30–48 290028 CurvePDF
CDL1-9CDLF1-9 CDL1950 0.55 0.4–2 33–54 290028 CurvePDF
CDL1-10CDLF1-10 CDL11050 0.55 0.4–2 36–60 290029 CurvePDF
CDL1-11CDLF1-11 CDL11150 0.55 0.4–2 40–66 290030 CurvePDF
CDL1-12CDLF1-12 CDL11250 0.75 0.4–2 44–72 290033 CurvePDF
CDL1-13CDLF1-13 CDL11350 0.75 0.4–2 47–78 290034 CurvePDF
CDL1-15CDLF1-15 CDL11550 0.75 0.4–2 55–89 290035 CurvePDF
CDL1-17CDLF1-17 CDL11750 1.1 0.4–2 62–101 290036 CurvePDF
CDL1-19CDLF1-19 CDL11950 1.1 0.4–2 69–113 290037 CurvePDF
CDL1-21CDLF1-21 CDL12150 1.1 0.4–2 75–124 290038 CurvePDF
CDL1-23CDLF1-23 CDL12350 1.1 0.4–2 82–137 290038 CurvePDF
CDL1-25CDLF1-25 CDL12550 1.5 0.4–2 89–149 290044 CurvePDF
CDL1-27CDLF1-27 CDL12750 1.5 0.4–2 95–161 290045 CurvePDF
CDL1-30CDLF1-30 CDL13050 1.5 0.4–2 106–178 290046 CurvePDF
CDL1-33CDLF1-33 CDL13350 2.2 0.4–2 118–196 290048 CurvePDF
CDL1-36CDLF1-36 CDL13650 2.2 0.4–2 130–214 290049 CurvePDF
CDL2-2CDLF2-2 CDL2250 0.37 1–3.5 8–18 290024 CurvePDF
CDL2-3CDLF2-3 CDL2350 0.37 1–3.5 12–27 290024 CurvePDF
CDL2-4CDLF2-4 CDL2450 0.55 1–3.5 16–36 290025 CurvePDF
CDL2-5CDLF2-5 CDL2550 0.55 1–3.5 20–45 290026 CurvePDF
CDL2-6CDLF2-6 CDL2650 0.75 1–3.5 24–53 290030 CurvePDF
CDL2-7CDLF2-7 CDL2750 0.75 1–3.5 28–63 290030 CurvePDF
CDL2-9CDLF2-9 CDL2950 1.1 1–3.5 37–80 290033 CurvePDF
CDL2-11CDLF2-11 CDL21150 1.1 1–3.5 44–98 290034 CurvePDF
CDL2-13CDLF2-13 CDL21350 1.5 1–3.5 52–116 290040 CurvePDF
CDL2-15CDLF2-15 CDL21550 1.5 1–3.5 60–134 290042 CurvePDF
CDL2-18CDLF2-18 CDL21850 2.2 1–3.5 76–161 290046 CurvePDF
CDL2-22CDLF2-22 CDL22250 2.2 1–3.5 90–197 290047 CurvePDF
CDL2-26CDLF2-26 CDL22650 3 1–3.5 110–232 290053 CurvePDF
CDL3-2CDLF3-2 CDL3250 0.37 1.2–4 6–12.5 290023 CurvePDF
CDL3-3CDLF3-3 CDL3350 0.37 1.2–4 9–19 290023 CurvePDF
CDL3-4CDLF3-4 CDL3450 0.37 1.2–4 12–25 290024 CurvePDF
CDL3-5CDLF3-5 CDL3550 0.37 1.2–4 16–31 290024 CurvePDF
CDL3-6CDLF3-6 CDL3650 0.55 1.2–4 19–36 290025 CurvePDF
CDL3-7CDLF3-7 CDL3750 0.55 1.2–4 22–43 290026 CurvePDF
CDL3-8CDLF3-8 CDL3850 0.75 1.2–4 25–49 290030 CurvePDF
CDL3-9CDLF3-9 CDL3950 0.75 1.2–4 28–55 290031 CurvePDF
CDL3-10CDLF3-10 CDL31050 0.75 1.2–4 31–61 290032 CurvePDF
CDL3-11CDLF3-11 CDL31150 1.1 1.2–4 34–67 290032 CurvePDF
CDL3-12CDLF3-12 CDL31250 1.1 1.2–4 37–73 290033 CurvePDF
CDL3-13CDLF3-13 CDL31350 1.1 1.2–4 40–78 290034 CurvePDF
CDL3-15CDLF3-15 CDL31550 1.1 1.2–4 46–90 290035 CurvePDF
CDL3-17CDLF3-17 CDL31750 1.5 1.2–4 52–103 290041 CurvePDF
CDL3-19CDLF3-19 CDL31950 1.5 1.2–4 58–115 290042 CurvePDF
CDL3-21CDLF3-21 CDL32150 2.2 1.2–4 64–128 290045 CurvePDF
CDL3-23CDLF3-23 CDL32350 2.2 1.2–4 70–140 290046 CurvePDF
CDL3-25CDLF3-25 CDL32550 2.2 1.2–4 76–151 290047 CurvePDF
CDL3-27CDLF3-27 CDL32750 2.2 1.2–4 82–164 290048 CurvePDF
CDL3-29CDLF3-29 CDL32950 2.2 1.2–4 88–175 290049 CurvePDF
CDL3-31CDLF3-31 CDL33150 3 1.2–4 94–187 290057 CurvePDF
CDL3-33CDLF3-33 CDL33350 3 1.2–4 100–199 290058 CurvePDF
CDL3-36CDLF3-36 CDL33650 3 1.2–4 109–218 290060 CurvePDF
CDL4-2CDLF4-2 CDL4250 0.37 1.5–7 8–19 290022 CurvePDF
CDL4-3CDLF4-3 CDL4350 0.55 1.5–7 13–28 290024 CurvePDF
CDL4-4CDLF4-4 CDL4450 0.75 1.5–7 19–38 290030 CurvePDF
CDL4-5CDLF4-5 CDL4550 1.1 1.5–7 23–47 290032 CurvePDF
CDL4-6CDLF4-6 CDL4650 1.1 1.5–7 28–56 290033 CurvePDF
CDL4-7CDLF4-7 CDL4750 1.5 1.5–7 33–66 290039 CurvePDF
CDL4-8CDLF4-8 CDL4850 1.5 1.5–7 38–74 290040 CurvePDF
CDL4-10CDLF4-10 CDL41050 2.2 1.5–7 48–96 290043 CurvePDF
CDL4-12CDLF4-12 CDL41250 2.2 1.5–7 58–114 290044 CurvePDF
CDL4-14CDLF4-14 CDL41450 3 1.5–7 68–136 290052 CurvePDF
CDL4-16CDLF4-16 CDL41650 3 1.5–7 78–152 290054 CurvePDF
CDL4-19CDLF4-19 CDL41950 4 1.5–7 93–183 290056 CurvePDF
CDL4-22CDLF4-22 CDL42250 4 1.5–7 108–211 290059 CurvePDF
CDL8-2/1CDLF8-2/1 CDL8250 0.75 5–12 6–10 290033 CurvePDF
CDL8-2CDLF8-2 CDL8250 0.75 5–12 13–20 290033 CurvePDF
CDL8-3CDLF8-3 CDL8350 1.1 5–12 19–30 290035 CurvePDF
CDL8-4CDLF8-4 CDL8450 1.5 5–12 26–41 290042 CurvePDF
CDL8-5CDLF8-5 CDL8550 2.2 5–12 32–52 290046 CurvePDF
CDL8-6CDLF8-6 CDL8650 2.2 5–12 39–62 290047 CurvePDF
CDL8-8CDLF8-8 CDL8850 3 5–12 52–83 290055 CurvePDF
CDL8-10CDLF8-10 CDL81050 4 5–12 65–104 290067 CurvePDF
CDL8-12CDLF8-12 CDL81250 4 5–12 78–124 290070 CurvePDF
CDL8-14CDLF8-14 CDL81450 5.5 5–12 92–145 290085 CurvePDF
CDL8-16CDLF8-16 CDL81650 5.5 5–12 106–166 290088 CurvePDF
CDL8-18CDLF8-18 CDL81850 7.5 5–12 120–187 290098 CurvePDF
CDL8-20CDLF8-20 CDL82050 7.5 5–12 135–208 290099 CurvePDF
CDL10-1CDLF10-1 CDL10150 0.75 5–13 4–9.7 290040 CurvePDF
CDL10-2CDLF10-2 CDL10250 0.75 5–13 10–19.5 290041 CurvePDF
CDL10-3CDLF10-3 CDL10350 1.1 5–13 16–29.5 290043 CurvePDF
CDL10-4CDLF10-4 CDL10450 1.5 5–13 22–39.5 290049 CurvePDF
CDL10-5CDLF10-5 CDL10550 2.2 5–13 28–49.5 290053 CurvePDF
CDL10-6CDLF10-6 CDL10650 2.2 5–13 34–60 290054 CurvePDF
CDL10-7CDLF10-7 CDL10750 3 5–13 39–70 290064 CurvePDF
CDL10-8CDLF10-8 CDL10850 3 5–13 44–80 290065 CurvePDF
CDL10-9CDLF10-9 CDL10950 3 5–13 50–90 290066 CurvePDF
CDL10-10CDLF10-10 CDL101050 4 5–13 56–100 290074 CurvePDF
CDL10-12CDLF10-12 CDL101250 4 5–13 68–120 290076 CurvePDF
CDL10-14CDLF10-14 CDL101450 5.5 5–13 79–140 2900100 CurvePDF
CDL10-16CDLF10-16 CDL101650 5.5 5–13 91–160 2900102 CurvePDF
CDL10-18CDLF10-18 CDL101850 7.5 5–13 102–180 2900107 CurvePDF
CDL10-20CDLF10-20 CDL102050 7.5 5–13 114–200 2900109 CurvePDF
CDL10-22CDLF10-22 CDL102250 7.5 5–13 126–220 2900111 CurvePDF
CDL12-2CDLF12-2 CDL12250 1.5 7–16 14–23.5 290040 CurvePDF
CDL12-3CDLF12-3 CDL12350 2.2 7–16 21–35.5 290045 CurvePDF
CDL12-4CDLF12-4 CDL12450 3 7–16 28–47 290055 CurvePDF
CDL12-5CDLF12-5 CDL12550 3 7–16 35–59.5 290057 CurvePDF
CDL12-6CDLF12-6 CDL12650 4 7–16 42–71.5 290066 CurvePDF
CDL12-7CDLF12-7 CDL12750 5.5 7–16 49–83.5 290077 CurvePDF
CDL12-8CDLF12-8 CDL12850 5.5 7–16 56–95.5 290078 CurvePDF
CDL12-9CDLF12-9 CDL12950 5.5 7–16 64–108 290080 CurvePDF
CDL12-10CDLF12-10 CDL121050 7.5 7–16 72–120 290088 CurvePDF
CDL12-12CDLF12-12 CDL121250 7.5 7–16 86–143.5 290092 CurvePDF
CDL12-14CDLF12-14 CDL121450 11 7–16 100–168 2900162 CurvePDF
CDL12-16CDLF12-16 CDL121650 11 7–16 115–192.5 2900167 CurvePDF
CDL12-18CDLF12-18 CDL121850 11 7–16 130–217 2900168 CurvePDF
CDL15-1CDLF15-1 CDL15150 1.1 8–22 6.5–12 290033 CurvePDF
CDL15-2CDLF15-2 CDL15250 2.2 8–22 16–25 290042 CurvePDF
CDL15-3CDLF15-3 CDL15350 3 8–22 25–39 290051 CurvePDF
CDL15-4CDLF15-4 CDL15450 4 8–22 33–52 290060 CurvePDF
CDL15-5CDLF15-5 CDL15550 4 8–22 42–65 290062 CurvePDF
CDL15-6CDLF15-6 CDL15650 5.5 8–22 51–78 290078 CurvePDF
CDL15-7CDLF15-7 CDL15750 5.5 8–22 60–92 290080 CurvePDF
CDL15-8CDLF15-8 CDL15850 7.5 8–22 69–106 290086 CurvePDF
CDL15-9CDLF15-9 CDL15950 7.5 8–22 79–120 290088 CurvePDF
CDL15-10CDLF15-10 CDL151050 11 8–22 88–133 2900166 CurvePDF
CDL15-12CDLF15-12 CDL151250 11 8–22 106–160 2900170 CurvePDF
CDL15-14CDLF15-14 CDL151450 11 8–22 124–187 2900173 CurvePDF
CDL15-17CDLF15-17 CDL151750 15 8–22 151–227 2900186 CurvePDF
CDL20-1CDLF20-1 CDL20150 1.1 10–28 6–13.5 290033 CurvePDF
CDL20-2CDLF20-2 CDL20250 2.2 10–28 15–27 290042 CurvePDF
CDL20-3CDLF20-3 CDL20350 4 10–28 24–40 290058 CurvePDF
CDL20-4CDLF20-4 CDL20450 5.5 10–28 33–54 290074 CurvePDF
CDL20-5CDLF20-5 CDL20550 5.5 10–28 40–67 290075 CurvePDF
CDL20-6CDLF20-6 CDL20650 7.5 10–28 49–81 290084 CurvePDF
CDL20-7CDLF20-7 CDL20750 7.5 10–28 58–95 290086 CurvePDF
CDL20-8CDLF20-8 CDL20850 11 10–28 67–109 2900157 CurvePDF
CDL20-10CDLF20-10 CDL201050 11 10–28 85–136 2900162 CurvePDF
CDL20-12CDLF20-12 CDL201250 15 10–28 102–164 2900176 CurvePDF
CDL20-14CDLF20-14 CDL201450 15 10–28 119–192 2900178 CurvePDF
CDL20-17CDLF20-17 CDL201750 18.5 10–28 145–234 2900201 CurvePDF
CDL32-10-1CDLF32-10-1 CDL32150 1.5 16–40 4–14 290063 CurvePDF
CDL32-10CDLF32-10 CDL32150 2.2 16–40 8–18 290067 CurvePDF
CDL32-20-2CDLF32-20-2 CDL32250 3 16–40 11–29 290076 CurvePDF
CDL32-20CDLF32-20 CDL32250 4 16–40 18–36 290084 CurvePDF
CDL32-30-2CDLF32-30-2 CDL32350 5.5 16–40 21–47 290099 CurvePDF
CDL32-30CDLF32-30 CDL32350 5.5 16–40 27–54 290099 CurvePDF
CDL32-40-2CDLF32-40-2 CDL32450 7.5 16–40 30–65 2900108 CurvePDF
CDL32-40CDLF32-40 CDL32450 7.5 16–40 37–72 2900108 CurvePDF
CDL32-50-2CDLF32-50-2 CDL32550 11 16–40 41–83 2900187 CurvePDF
CDL32-50CDLF32-50 CDL32550 11 16–40 47–90 2900187 CurvePDF
CDL32-60-2CDLF32-60-2 CDL32650 11 16–40 51–101 2900193 CurvePDF
CDL32-60CDLF32-60 CDL32650 11 16–40 57–108 2900193 CurvePDF
CDL32-70-2CDLF32-70-2 CDL32750 15 16–40 60–119 2900205 CurvePDF
CDL32-70CDLF32-70 CDL32750 15 16–40 67–126 2900205 CurvePDF
CDL32-80-2CDLF32-80-2 CDL32850 15 16–40 71–136 2900207 CurvePDF
CDL32-80CDLF32-80 CDL32850 15 16–40 77–144 2900207 CurvePDF
CDL32-90-2CDLF32-90-2 CDL32950 18.5 16–40 82–154 2900226 CurvePDF
CDL32-90CDLF32-90 CDL32950 18.5 16–40 88–162 2900226 CurvePDF
CDL32-100-2CDLF32-100-2 CDL321050 18.5 16–40 91–175 2900232 CurvePDF
CDL32-100CDLF32-100 CDL321050 18.5 16–40 98–182 2900232 CurvePDF
CDL32-110-2CDLF32-110-2 CDL321150 22 16–40 102–193 2900278 CurvePDF
CDL32-110CDLF32-110 CDL321150 22 16–40 109–200 2900278 CurvePDF
CDL32-120-2CDLF32-120-2 CDL321250 22 16–40 113–211 2900282 CurvePDF
CDL32-120CDLF32-120 CDL321250 22 16–40 120–218 2900282 CurvePDF
CDL32-130-2CDLF32-130-2 CDL321350 30 16–40 124–230 2900343 CurvePDF
CDL32-130CDLF32-130 CDL321350 30 16–40 131–237 2900343 CurvePDF
CDL32-140-2CDLF32-140-2 CDL321450 30 16–40 135–247 2900347 CurvePDF
CDL32-140CDLF32-140 CDL321450 30 16–40 142–255 2900347 CurvePDF
CDL32-150-2CDLF32-150-2 CDL321550 30 16–40 145–266 2900350 CurvePDF
CDL32-150CDLF32-150 CDL321550 30 16–40 152–274 2900350 CurvePDF
CDL32-160-2CDLF32-160-2 CDL321650 30 16–40 156–284 2900356 CurvePDF
CDL32-160CDLF32-160 CDL321650 30 16–40 163–292 2900356 CurvePDF
CDL42-10-1CDLF42-10-1 CDL42150 3 25–55 11–20 290084 CurvePDF
CDL42-10CDLF42-10 CDL42150 4 25–55 16–24 290091 CurvePDF
CDL42-20-2CDLF42-20-2 CDL42250 5.5 25–55 23–40 2900106 CurvePDF
CDL42-20CDLF42-20 CDL42250 7.5 25–55 31–48 2900111 CurvePDF
CDL42-30-2CDLF42-30-2 CDL42350 11 25–55 38–63 2900187 CurvePDF
CDL42-30CDLF42-30 CDL42350 11 25–55 47–71 2900187 CurvePDF
CDL42-40-2CDLF42-40-2 CDL42450 15 25–55 54–87 2900203 CurvePDF
CDL42-40CDLF42-40 CDL42450 15 25–55 62–95 2900203 CurvePDF
CDL42-50-2CDLF42-50-2 CDL42550 18.5 25–55 69–111 2900225 CurvePDF
CDL42-50CDLF42-50 CDL42550 18.5 25–55 78–119 2900225 CurvePDF
CDL42-60-2CDLF42-60-2 CDL42650 22 25–55 85–135 2900266 CurvePDF
CDL42-60CDLF42-60 CDL42650 22 25–55 93–143 2900266 CurvePDF
CDL42-70-2CDLF42-70-2 CDL42750 30 25–55 100–158 2900326 CurvePDF
CDL42-70CDLF42-70 CDL42750 30 25–55 109–166 2900326 CurvePDF
CDL42-80-2CDLF42-80-2 CDL42850 30 25–55 116–182 2900330 CurvePDF
CDL42-80CDLF42-80 CDL42850 30 25–55 124–190 2900330 CurvePDF
CDL42-90-2CDLF42-90-2 CDL42950 30 25–55 132–205 2900334 CurvePDF
CDL42-90CDLF42-90 CDL42950 37 25–55 140–214 2900334 CurvePDF
CDL42-100-2CDLF42-100-2 CDL421050 37 25–55 147–230 2900360 CurvePDF
CDL42-100CDLF42-100 CDL421050 37 25–55 155–238 2900360 CurvePDF
CDL42-110-2CDLF42-110-2 CDL421150 45 25–55 165–255 2900430 CurvePDF
CDL42-110CDLF42-110 CDL421150 45 25–55 173–263 2900430 CurvePDF
CDL42-120-2CDLF42-120-2 CDL421250 45 25–55 181–280 2900438 CurvePDF
CDL42-120CDLF42-120 CDL421250 45 25–55 190–289 2900438 CurvePDF
CDL42-130-2CDLF42-130-2 CDL421350 45 25–55 198–305 2900444 CurvePDF
CDL65-10-1CDLF65-10-1 CDL65150 4 30–80 8–19 290098 CurvePDF
CDL65-10CDLF65-10 CDL65150 5.5 30–80 15–27 2900110 CurvePDF
CDL65-20-2CDLF65-20-2 CDL65250 7.5 30–80 17–39 2900115 CurvePDF
CDL65-20-1CDLF65-20-1 CDL65250 11 30–80 24–46 2900197 CurvePDF
CDL65-20CDLF65-20 CDL65250 11 30–80 30–53 2900197 CurvePDF
CDL65-30-2CDLF65-30-2 CDL65350 15 30–80 32–66 2900206 CurvePDF
CDL65-30-1CDLF65-30-1 CDL65350 15 30–80 39–73 2900207 CurvePDF
CDL65-30CDLF65-30 CDL65350 18.5 30–80 46–80 2900232 CurvePDF
CDL65-40-2CDLF65-40-2 CDL65450 18.5 30–80 47–92 2900239 CurvePDF
CDL65-40-1CDLF65-40-1 CDL65450 22 30–80 54–100 2900272 CurvePDF
CDL65-40CDLF65-40 CDL65450 22 30–80 61–107 2900272 CurvePDF
CDL65-50-2CDLF65-50-2 CDL65550 30 30–80 64–121 2900334 CurvePDF
CDL65-50-1CDLF65-50-1 CDL65550 30 30–80 71–128 2900334 CurvePDF
CDL65-50CDLF65-50 CDL65550 30 30–80 78–136 2900335 CurvePDF
CDL65-60-2CDLF65-60-2 CDL65650 30 30–80 81–150 2900340 CurvePDF
CDL65-60-1CDLF65-60-1 CDL65650 37 30–80 88–157 2900365 CurvePDF
CDL65-60CDLF65-60 CDL65650 37 30–80 95–164 2900365 CurvePDF
CDL65-70-2CDLF65-70-2 CDL65750 37 30–80 99–179 2900370 CurvePDF
CDL65-70-1CDLF65-70-1 CDL65750 37 30–80 106–186 2900370 CurvePDF
CDL65-70CDLF65-70 CDL65750 45 30–80 112–193 2900437 CurvePDF
CDL65-80-2CDLF65-80-2 CDL65850 45 30–80 116–207 2900440 CurvePDF
CDL65-80-1CDLF65-80-1 CDL65850 45 30–80 123–215 2900440 CurvePDF
CDL85-10-1CDLF85-10-1 CDL85150 5.5 50–110 6–22 2900109 CurvePDF
CDL85-10CDLF85-10 CDL85150 7.5 50–110 12–25 2900115 CurvePDF
CDL85-20-2CDLF85-20-2 CDL85250 11 50–110 15–41 2900185 CurvePDF
CDL85-20CDLF85-20 CDL85250 15 50–110 30–53 2900202 CurvePDF
CDL85-30-2CDLF85-30-2 CDL85350 18.5 50–110 32–68 2900225 CurvePDF
CDL85-30CDLF85-30 CDL85350 22 50–110 48–81 2900268 CurvePDF
CDL85-40-2CDLF85-40-2 CDL85450 30 50–110 50–98 2900328 CurvePDF
CDL85-40CDLF85-40 CDL85450 30 50–110 66–110 2900328 CurvePDF
CDL85-50-2CDLF85-50-2 CDL85550 37 50–110 68–126 2900351 CurvePDF
CDL85-50CDLF85-50 CDL85550 37 50–110 83–139 2900351 CurvePDF
CDL85-60-2CDLF85-60-2 CDL85650 45 50–110 86–155 2900428 CurvePDF
CDL85-60CDLF85-60 CDL85650 45 50–110 103–168 2900428 CurvePDF
CDL120-10CDLF120-10 CDL120150 11 60–150 15–22 2900226 CurvePDF
CDL120-20-2CDLF120-20-2 CDL120250 15 60–150 24–34 2900250 CurvePDF
CDL120-20-1CDLF120-20-1 CDL120250 18.5 60–150 27.5–41 2900263 CurvePDF
CDL120-20CDLF120-20 CDL120250 22 60–150 33.5–46 2900310 CurvePDF
CDL120-30-2CDLF120-30-2 CDL120350 30 60–150 41–57 2900375 CurvePDF
CDL120-30-1CDLF120-30-1 CDL120350 30 60–150 46–64 2900375 CurvePDF
CDL120-30CDLF120-30 CDL120350 30 60–150 51–69.5 2900375 CurvePDF
CDL120-40-2CDLF120-40-2 CDL120450 37 60–150 58–80.5 2900405 CurvePDF
CDL120-40-1CDLF120-40-1 CDL120450 37 60–150 64.5–87 2900405 CurvePDF
CDL120-40CDLF120-40 CDL120450 45 60–150 68.5–92.5 2900501 CurvePDF
CDL120-50-2CDLF120-50-2 CDL120550 45 60–150 75.5–104.5 2900509 CurvePDF
CDL120-50-1CDLF120-50-1 CDL120550 45 60–150 83–110.5 2900509 CurvePDF
CDL120-50CDLF120-50 CDL120550 55 60–150 86–115.5 2900632 CurvePDF
CDL120-60-2CDLF120-60-2 CDL120650 55 60–150 92.5–128 2900641 CurvePDF
CDL120-60-1CDLF120-60-1 CDL120650 55 60–150 100–134 2900641 CurvePDF
CDL120-60CDLF120-60 CDL120650 75 60–150 104–139 2900757 CurvePDF
CDL120-70-2CDLF120-70-2 CDL120750 75 60–150 109–151 2900766 CurvePDF
CDL120-70-1CDLF120-70-1 CDL120750 75 60–150 116.5–156.5 2900766 CurvePDF
CDL120-70CDLF120-70 CDL120750 75 60–150 123–162.5 2900766 CurvePDF
CDL150-10-1CDLF150-10-1 CDL150150 11 80–180 8.5–18.3 2900227 CurvePDF
CDL150-10CDLF150-10 CDL150150 15 80–180 15–24 2900240 CurvePDF
CDL150-20-2CDLF150-20-2 CDL150250 18.5 80–180 21–37 2900263 CurvePDF
CDL150-20-1CDLF150-20-1 CDL150250 22 80–180 27–44.3 2900311 CurvePDF
CDL150-20CDLF150-20 CDL150250 30 80–180 32–50 2900364 CurvePDF
CDL150-30-2CDLF150-30-2 CDL150350 30 80–180 39–63.5 2900374 CurvePDF
CDL150-30-1CDLF150-30-1 CDL150350 37 80–180 45–70 2900395 CurvePDF
CDL150-30CDLF150-30 CDL150350 37 80–180 50.5–78 2900395 CurvePDF
CDL150-40-2CDLF150-40-2 CDL150450 45 80–180 56–89 2900502 CurvePDF
CDL150-40-1CDLF150-40-1 CDL150450 45 80–180 62–96.5 2900502 CurvePDF
CDL150-40CDLF150-40 CDL150450 55 80–180 68–104 2900625 CurvePDF
CDL150-50-2CDLF150-50-2 CDL150550 55 80–180 73.5–115.5 2900636 CurvePDF
CDL150-50-1CDLF150-50-1 CDL150550 75 80–180 80–122.5 2900752 CurvePDF
CDL150-50CDLF150-50 CDL150550 75 80–180 86.5–130 2900752 CurvePDF
CDL150-60-2CDLF150-60-2 CDL150650 75 80–180 91–140 2900762 CurvePDF
CDL150-60-1CDLF150-60-1 CDL150650 75 80–180 97.5–148.5 2900762 CurvePDF
CDL150-60CDLF150-60 CDL150650 75 80–180 109–157 2900762 CurvePDF
CDL200-10-BCDLF200-10-B CDL200150 18.5 100–240 15.5–25.5 2900343 CurvePDF
CDL200-10-ACDLF200-10-A CDL200150 22 100–240 20–29 2900390 CurvePDF
CDL200-10CDLF200-10 CDL200150 30 100–240 30–38.5 2900443 CurvePDF
CDL200-20-2BCDLF200-20-2B CDL200250 37 100–240 32–53 2900482 CurvePDF
CDL200-20-2ACDLF200-20-2A CDL200250 45 100–240 40.5–59.5 2900578 CurvePDF
CDL200-20-ACDLF200-20-A CDL200250 55 100–240 51–69 2900710 CurvePDF
CDL200-20CDLF200-20 CDL200250 55 100–240 61.5–78.5 2900710 CurvePDF
CDL200-30-2BCDLF200-30-2B CDL200350 75 100–240 63–91.5 2900845 CurvePDF
CDL200-30-A-BCDLF200-30-A-B CDL200350 75 100–240 67–95 2900845 CurvePDF
CDL200-30-2ACDLF200-30-2A CDL200350 75 100–240 72–99.5 2900845 CurvePDF
CDL200-30-BCDLF200-30-B CDL200350 75 100–240 77.5–104.5 2900845 CurvePDF
CDL200-30-ACDLF200-30-A CDL200350 75 100–240 81.5–108 2900845 CurvePDF
CDL200-30CDLF200-30 CDL200350 90 100–240 92–117.5 2900921 CurvePDF
CDL200-40-2BCDLF200-40-2B CDL200450 90 100–240 94–131.5 2900938 CurvePDF
CDL200-40-2ACDLF200-40-2A CDL200450 110 100–240 102.5–138.5 29001148 CurvePDF
CDL200-40-ACDLF200-40-A CDL200450 110 100–240 113–148 29001148 CurvePDF
CDL200-40CDLF200-40 CDL200450 110 100–240 123.5–157.5 29001148 CurvePDF
CDL1-2CDLF1-2 CDL1260 0.37 0.6–2 13–17.5 350020 CurvePDF
CDL1-3CDLF1-3 CDL1360 0.37 0.6–2 20–26.5 350020 CurvePDF
CDL1-4CDLF1-4 CDL1460 0.37 0.6–2 26–35 350021 CurvePDF
CDL1-5CDLF1-5 CDL1560 0.55 0.6–2 33–43 350022 CurvePDF
CDL1-6CDLF1-6 CDL1660 0.55 0.6–2 39–52 350023 CurvePDF
CDL1-7CDLF1-7 CDL1760 0.75 0.6–2 46–60 350026 CurvePDF
CDL1-8CDLF1-8 CDL1860 0.75 0.6–2 53–68 350027 CurvePDF
CDL1-9CDLF1-9 CDL1960 0.75 0.6–2 60–76 350028 CurvePDF
CDL1-10CDLF1-10 CDL11060 1.1 0.6–2 67–85 350029 CurvePDF
CDL1-11CDLF1-11 CDL11160 1.1 0.6–2 73–95 350029 CurvePDF
CDL1-12CDLF1-12 CDL11260 1.1 0.6–2 79–103 350030 CurvePDF
CDL1-13CDLF1-13 CDL11360 1.1 0.6–2 86–112 350031 CurvePDF
CDL1-15CDLF1-15 CDL11560 1.5 0.6–2 99–127 350037 CurvePDF
CDL1-17CDLF1-17 CDL11760 1.5 0.6–2 112–144 350038 CurvePDF
CDL1-19CDLF1-19 CDL11960 2.2 0.6–2 124–160 350041 CurvePDF
CDL1-21CDLF1-21 CDL12160 2.2 0.6–2 138–177 350042 CurvePDF
CDL1-23CDLF1-23 CDL12360 2.2 0.6–2 152–193 350043 CurvePDF
CDL1-25CDLF1-25 CDL12560 3 0.6–2 164–210 350051 CurvePDF
CDL2-2CDLF2-2 CDL2260 0.55 1–4.5 9–26 350021 CurvePDF
CDL2-3CDLF2-3 CDL2360 0.75 1–4.5 15–39 350024 CurvePDF
CDL2-4CDLF2-4 CDL2460 1.1 1–4.5 20–52 350025 CurvePDF
CDL2-5CDLF2-5 CDL2560 1.1 1–4.5 25–65 350026 CurvePDF
CDL2-6CDLF2-6 CDL2660 1.1 1–4.5 30–78 350026 CurvePDF
CDL2-7CDLF2-7 CDL2760 1.5 1–4.5 35–91 350032 CurvePDF
CDL2-9CDLF2-9 CDL2960 2.2 1–4.5 45–117 350036 CurvePDF
CDL2-11CDLF2-11 CDL21160 2.2 1–4.5 56–143 350037 CurvePDF
CDL2-13CDLF2-13 CDL21360 3 1–4.5 66–171 350044 CurvePDF
CDL2-15CDLF2-15 CDL21560 3 1–4.5 77–195 350045 CurvePDF
CDL2-18CDLF2-18 CDL21860 4 1–4.5 94–234 350054 CurvePDF
CDL3-2CDLF3-2 CDL3260 0.37 1.5–5 8–17.5 350020 CurvePDF
CDL3-3CDLF3-3 CDL3360 0.55 1.5–5 12–26.5 350021 CurvePDF
CDL3-4CDLF3-4 CDL3460 0.55 1.5–5 17–35 350022 CurvePDF
CDL3-5CDLF3-5 CDL3560 0.75 1.5–5 23–44 350025 CurvePDF
CDL3-6CDLF3-6 CDL3660 1.1 1.5–5 27–51 350026 CurvePDF
CDL3-7CDLF3-7 CDL3760 1.1 1.5–5 31–61 350027 CurvePDF
CDL3-8CDLF3-8 CDL3860 1.1 1.5–5 35–70 350027 CurvePDF
CDL3-9CDLF3-9 CDL3960 1.5 1.5–5 40–78 350033 CurvePDF
CDL3-10CDLF3-10 CDL31060 1.5 1.5–5 44–87 350034 CurvePDF
CDL3-11CDLF3-11 CDL31160 1.5 1.5–5 48–96 350034 CurvePDF
CDL3-12CDLF3-12 CDL31260 2.2 1.5–5 52–104 350037 CurvePDF
CDL3-13CDLF3-13 CDL31360 2.2 1.5–5 57–112 350038 CurvePDF
CDL3-15CDLF3-15 CDL31560 2.2 1.5–5 65–129 350039 CurvePDF
CDL3-17CDLF3-17 CDL31760 2.2 1.5–5 74–147 350040 CurvePDF
CDL3-19CDLF3-19 CDL31960 3 1.5–5 82–165 350048 CurvePDF
CDL3-21CDLF3-21 CDL32160 3 1.5–5 91–183 350049 CurvePDF
CDL3-23CDLF3-23 CDL32360 3 1.5–5 98–200 350050 CurvePDF
CDL3-25CDLF3-25 CDL32560 4 1.5–5 108–217 350058 CurvePDF
CDL4-2CDLF4-2 CDL4260 0.75 2.5–8 14–26 350024 CurvePDF
CDL4-3CDLF4-3 CDL4360 1.1 2.5–8 21–39 350025 CurvePDF
CDL4-4CDLF4-4 CDL4460 1.5 2.5–8 31–52 350031 CurvePDF
CDL4-5CDLF4-5 CDL4560 2.2 2.5–8 39–65 350034 CurvePDF
CDL4-6CDLF4-6 CDL4660 2.2 2.5–8 47–78 350035 CurvePDF
CDL4-7CDLF4-7 CDL4760 3 2.5–8 55–92 350042 CurvePDF
CDL4-8CDLF4-8 CDL4860 3 2.5–8 63–104 350042 CurvePDF
CDL4-10CDLF4-10 CDL41060 4 2.5–8 80–130 350051 CurvePDF
CDL4-12CDLF4-12 CDL41260 4 2.5–8 96–156 350052 CurvePDF
CDL4-14CDLF4-14 CDL41460 5.5 2.5–8 112–182 350064 CurvePDF
CDL4-16CDLF4-16 CDL41660 5.5 2.5–8 128–207 350066 CurvePDF
CDL8-2/1CDLF8-2/1 CDL8260 0.75 7–14 9–13 350032 CurvePDF
CDL8-2CDLF8-2 CDL8260 1.5 7–14 18–27 350038 CurvePDF
CDL8-3CDLF8-3 CDL8360 2.2 7–14 28–41 350041 CurvePDF
CDL8-4CDLF8-4 CDL8460 3 7–14 38–55 350049 CurvePDF
CDL8-5CDLF8-5 CDL8560 3 7–14 47–70 350050 CurvePDF
CDL8-6CDLF8-6 CDL8660 4 7–14 57–85 350058 CurvePDF
CDL8-8CDLF8-8 CDL8860 5.5 7–14 75–115 350071 CurvePDF
CDL8-10CDLF8-10 CDL81060 7.5 7–14 95–145 350080 CurvePDF
CDL8-12CDLF8-12 CDL81260 7.5 7–14 115–173 350082 CurvePDF
CDL8-14CDLF8-14 CDL81460 11 7–14 135–202 3500153 CurvePDF
CDL10-1CDLF10-1 CDL10160 0.75 6–15 6–14 350040 CurvePDF
CDL10-2CDLF10-2 CDL10260 1.5 6–15 16–29 350047 CurvePDF
CDL10-3CDLF10-3 CDL10360 2.2 6–15 25–43 350051 CurvePDF
CDL10-4CDLF10-4 CDL10460 3 6–15 34–58 350060 CurvePDF
CDL10-5CDLF10-5 CDL10560 3 6–15 43–72 350061 CurvePDF
CDL10-6CDLF10-6 CDL10660 4 6–15 52–87 350070 CurvePDF
CDL10-7CDLF10-7 CDL10760 5.5 6–15 61–102 350092 CurvePDF
CDL10-8CDLF10-8 CDL10860 5.5 6–15 70–117 350093 CurvePDF
CDL10-9CDLF10-9 CDL10960 5.5 6–15 79–131 350094 CurvePDF
CDL10-10CDLF10-10 CDL101060 7.5 6–15 89–146 350098 CurvePDF
CDL10-12CDLF10-12 CDL101260 7.5 6–15 107–175 3500100 CurvePDF
CDL10-14CDLF10-14 CDL101460 11 6–15 125–204 3500157 CurvePDF
CDL10-16CDLF10-16 CDL101660 11 6–15 143–233 3500159 CurvePDF
CDL10-17CDLF10-17 CDL101760 11 6–15 152–248 3500160 CurvePDF
CDL12-1CDLF12-1 CDL12160 1.1 7–19 8.5–17 350032 CurvePDF
CDL12-2CDLF12-2 CDL12260 2.2 7–19 20.5–35 350041 CurvePDF
CDL12-3CDLF12-3 CDL12360 4 7–19 31–52.5 350056 CurvePDF
CDL12-4CDLF12-4 CDL12460 5.5 7–19 41–70 350069 CurvePDF
CDL12-5CDLF12-5 CDL12560 5.5 7–19 51–88 350071 CurvePDF
CDL12-6CDLF12-6 CDL12660 7.5 7–19 61–107 350077 CurvePDF
CDL12-7CDLF12-7 CDL12760 7.5 7–19 71–124 350078 CurvePDF
CDL12-8CDLF12-8 CDL12860 11 7–19 82–141 3500147 CurvePDF
CDL12-10CDLF12-10 CDL121060 11 7–19 104–178 3500151 CurvePDF
CDL12-12CDLF12-12 CDL121260 15 7–19 125–213 3500164 CurvePDF
CDL12-14CDLF12-14 CDL121460 15 7–19 145–249 3500167 CurvePDF
CDL15-1CDLF15-1 CDL15160 1.5 10–26 9.5–17.5 350039 CurvePDF
CDL15-2CDLF15-2 CDL15260 3 10–26 24–36.5 350049 CurvePDF
CDL15-3CDLF15-3 CDL15360 4 10–26 37–56 350058 CurvePDF
CDL15-4CDLF15-4 CDL15460 5.5 10–26 49–75 350071 CurvePDF
CDL15-5CDLF15-5 CDL15560 7.5 10–26 62–94 350081 CurvePDF
CDL15-6CDLF15-6 CDL15660 11 10–26 76–113 3500150 CurvePDF
CDL15-7CDLF15-7 CDL15760 11 10–26 90–134 3500152 CurvePDF
CDL15-8CDLF15-8 CDL15860 11 10–26 103–154 3500153 CurvePDF
CDL15-9CDLF15-9 CDL15960 15 10–26 118–174 3500165 CurvePDF
CDL15-10CDLF15-10 CDL151060 15 10–26 131–193 3500167 CurvePDF
CDL15-12CDLF15-12 CDL151260 18.5 10–26 158–232 3500191 CurvePDF
CDL20-1CDLF20-1 CDL20160 2.2 12–34 8.5–19 350041 CurvePDF
CDL20-2CDLF20-2 CDL20260 4 12–34 21–38 350056 CurvePDF
CDL20-3CDLF20-3 CDL20360 5.5 12–34 33–58 350069 CurvePDF
CDL20-4CDLF20-4 CDL20460 7.5 12–34 45–78 350079 CurvePDF
CDL20-5CDLF20-5 CDL20560 11 12–34 57–98 3500148 CurvePDF
CDL20-6CDLF20-6 CDL20660 11 12–34 70–118 3500150 CurvePDF
CDL20-7CDLF20-7 CDL20760 15 12–34 83–138 3500162 CurvePDF
CDL20-8CDLF20-8 CDL20860 15 12–34 96–158 3500163 CurvePDF
CDL20-10CDLF20-10 CDL201060 18.5 12–34 122–198 3500187 CurvePDF
CDL32-10-1CDLF32-10-1 CDL32160 3 20–48 7–20 350073 CurvePDF
CDL32-10CDLF32-10 CDL32160 4 20–48 14–26 350081 CurvePDF
CDL32-20-2CDLF32-20-2 CDL32260 5.5 20–48 17–41 350095 CurvePDF
CDL32-20CDLF32-20 CDL32260 7.5 20–48 27–52 3500101 CurvePDF
CDL32-30-2CDLF32-30-2 CDL32360 7.5 20–48 31–67 3500104 CurvePDF
CDL32-30CDLF32-30 CDL32360 11 20–48 40–78 3500172 CurvePDF
CDL32-40-2CDLF32-40-2 CDL32460 11 20–48 45–94 3500176 CurvePDF
CDL32-40CDLF32-40 CDL32460 15 20–48 55–104 3500186 CurvePDF
CDL32-50-2CDLF32-50-2 CDL32560 15 20–48 59–119 3500191 CurvePDF
CDL32-50CDLF32-50 CDL32560 18.5 20–48 69–130 3500211 CurvePDF
CDL32-60-2CDLF32-60-2 CDL32660 18.5 20–48 74–145 3500216 CurvePDF
CDL32-60CDLF32-60 CDL32660 18.5 20–48 81–155 3500216 CurvePDF
CDL32-70-2CDLF32-70-2 CDL32760 22 20–48 86–172 3500255 CurvePDF
CDL32-70CDLF32-70 CDL32760 22 20–48 97–182 3500255 CurvePDF
CDL32-80-2CDLF32-80-2 CDL32860 22 20–48 102–196 3500259 CurvePDF
CDL32-80CDLF32-80 CDL32860 30 20–48 111–208 3500315 CurvePDF
CDL32-90-2CDLF32-90-2 CDL32960 30 20–48 117–223 3500319 CurvePDF
CDL32-90CDLF32-90 CDL32960 30 20–48 127–234 3500319 CurvePDF
CDL32-100-2CDLF32-100-2 CDL321060 30 20–48 133–248 3500324 CurvePDF
CDL42-10-1CDLF42-10-1 CDL42160 5.5 30–65 16–29 3500101 CurvePDF
CDL42-10CDLF42-10 CDL42160 7.5 30–65 22–34 3500106 CurvePDF
CDL42-20-2CDLF42-20-2 CDL42260 11 30–65 33–57 3500178 CurvePDF
CDL42-20CDLF42-20 CDL42260 15 30–65 44–69 3500188 CurvePDF
CDL42-30-2CDLF42-30-2 CDL42360 18.5 30–65 55–90 3500213 CurvePDF
CDL42-30CDLF42-30 CDL42360 18.5 30–65 68–102 3500213 CurvePDF
CDL42-40-2CDLF42-40-2 CDL42460 22 30–65 78–125 3500253 CurvePDF
CDL42-40CDLF42-40 CDL42460 30 30–65 89–136 3500309 CurvePDF
CDL42-50-2CDLF42-50-2 CDL42560 30 30–65 99–159 3500313 CurvePDF
CDL42-50CDLF42-50 CDL42560 30 30–65 112–171 3500313 CurvePDF
CDL42-60-2CDLF42-60-2 CDL42660 37 30–65 122–194 3500340 CurvePDF
CDL42-60CDLF42-60 CDL42660 37 30–65 134–205 3500340 CurvePDF
CDL42-70-2CDLF42-70-2 CDL42760 45 30–65 144–227 3500404 CurvePDF
CDL42-70CDLF42-70 CDL42760 45 30–65 157–239 3500404 CurvePDF
CDL65-10-1CDLF65-10-1 CDL65160 7.5 40–100 10–26 3500109 CurvePDF
CDL65-10CDLF65-10 CDL65160 11 40–100 21–37 3500177 CurvePDF
CDL65-20-2CDLF65-20-2 CDL65260 15 40–100 23–53 3500187 CurvePDF
CDL65-20CDLF65-20 CDL65260 22 40–100 42–74 3500248 CurvePDF
CDL65-30-2CDLF65-30-2 CDL65360 22 40–100 45–93 3500252 CurvePDF
CDL65-30CDLF65-30 CDL65360 30 40–100 65–112 3500313 CurvePDF
CDL65-40-2CDLF65-40-2 CDL65460 37 40–100 66–130 3500336 CurvePDF
CDL65-40CDLF65-40 CDL65460 45 40–100 86–152 3500398 CurvePDF
CDL65-50-2CDLF65-50-2 CDL65560 45 40–100 91–172 3500402 CurvePDF
CDL85-10-1CDLF85-10-1 CDL85160 11 60–130 9–31 3500177 CurvePDF
CDL85-10CDLF85-10 CDL85160 15 60–130 18–36 3500188 CurvePDF
CDL85-20-2CDLF85-20-2 CDL85260 18.5 60–130 22–59 3500211 CurvePDF
CDL85-20-1CDLF85-20-1 CDL85260 22 60–130 33–67 3500248 CurvePDF
CDL85-20CDLF85-20 CDL85260 30 60–130 44–76 3500304 CurvePDF
CDL85-30-2CDLF85-30-2 CDL85360 37 60–130 46–98 3500330 CurvePDF
CDL85-30-1CDLF85-30-1 CDL85360 37 60–130 56–108 3500330 CurvePDF
CDL85-30CDLF85-30 CDL85360 45 60–130 69–116 3500392 CurvePDF
CDL85-40-2CDLF85-40-2 CDL85460 45 60–130 72–141 3500396 CurvePDF
CDL120-10-1CDLF120-10-1 CDL120160 15 60–160 20–26.5 3540235 CurvePDF
CDL120-10CDLF120-10 CDL120160 18.5 60–160 24.4–30.8 3540250 CurvePDF
CDL120-20-2CDLF120-20-2 CDL120260 30 60–160 38.5–51.5 3540350 CurvePDF
CDL120-20-1CDLF120-20-1 CDL120260 30 60–160 45–58.3 3540350 CurvePDF
CDL120-20CDLF120-20 CDL120260 37 60–160 54.6–66.3 3540380 CurvePDF
CDL120-30-2CDLF120-30-2 CDL120360 45 60–160 65–83 3540445 CurvePDF
CDL120-30-1CDLF120-30-1 CDL120360 45 60–160 73.3–91.3 3540445 CurvePDF
CDL120-30CDLF120-30 CDL120360 55 60–160 82.7–100.3 3540545 CurvePDF
CDL120-40-2CDLF120-40-2 CDL120460 75 60–160 93–116 3540675 CurvePDF
CDL120-40-1CDLF120-40-1 CDL120460 75 60–160 103–126 3540675 CurvePDF
CDL120-40CDLF120-40 CDL120460 75 60–160 109.5–134 3540675 CurvePDF
CDL120-50-2CDLF120-50-2 CDL120560 75 60–160 122–152 3540690 CurvePDF
CDL150-10-1CDLF150-10-1 CDL150160 15 80–180 18–26.5 3540235 CurvePDF
CDL150-10CDLF150-10 CDL150160 22 80–180 27–35 3540280 CurvePDF
CDL150-20-2CDLF150-20-2 CDL150260 30 80–180 43–57 3540360 CurvePDF
CDL150-20-1CDLF150-20-1 CDL150260 37 80–180 51–67 3540380 CurvePDF
CDL150-20CDLF150-20 CDL150260 45 80–180 59–75.5 3540435 CurvePDF
CDL150-30-2CDLF150-30-2 CDL150360 55 80–180 72.5–94 3540545 CurvePDF
CDL150-30-1CDLF150-30-1 CDL150360 75 80–180 80–104 3540665 CurvePDF
CDL150-30CDLF150-30 CDL150360 75 80–180 89.4–114.4 3540665 CurvePDF
CDL150-40-2CDLF150-40-2 CDL150460 75 80–180 102.5–133 3540680 CurvePDF
CDL200-10-BCDLF200-10-B CDL200160 30 100–240 29–38 3540403 CurvePDF
CDL200-10-ACDLF200-10-A CDL200160 37 100–240 34.5–43 3540426 CurvePDF
CDL200-10CDLF200-10 CDL200160 45 100–240 48.5–56 3540484 CurvePDF
CDL200-20-2BCDLF200-20-2B CDL200260 55 100–240 58.5–77.5 3540595 CurvePDF
CDL200-20-2ACDLF200-20-2A CDL200260 75 100–240 70–87 3540718 CurvePDF
CDL200-20-BCDLF200-20-B CDL200260 75 100–240 79–95.5 3540718 CurvePDF
CDL200-20-ACDLF200-20-A CDL200260 90 100–240 84–100 3540787 CurvePDF
CDL200-20CDLF200-20 CDL200260 90 100–240 98.5–114 3540787 CurvePDF
CDL200-30-2BCDLF200-30-2B CDL200360 110 100–240 108.5–135 35401158 CurvePDF
CDL200-30-A-BCDLF200-30-A-B CDL200360 110 100–240 113.5–139 35401158 CurvePDF
CDL200-30-2ACDLF200-30-2A CDL200360 110 100–240 120–145 35401158 CurvePDF

Performance range

Every model of the CDL / CDLF range on one chart: each line is the performance curve of one model. Click a line or dot to open that model with its full data.

0.51251020501002005102050100200Flow (m³/h)Head (m)CDL1-2 · 50 HzCDL1-3 · 50 HzCDL1-4 · 50 HzCDL1-5 · 50 HzCDL1-6 · 50 HzCDL1-7 · 50 HzCDL1-8 · 50 HzCDL1-9 · 50 HzCDL1-10 · 50 HzCDL1-11 · 50 HzCDL1-12 · 50 HzCDL1-13 · 50 HzCDL1-15 · 50 HzCDL1-17 · 50 HzCDL1-19 · 50 HzCDL1-21 · 50 HzCDL1-23 · 50 HzCDL1-25 · 50 HzCDL1-27 · 50 HzCDL1-30 · 50 HzCDL1-33 · 50 HzCDL1-36 · 50 HzCDL2-2 · 50 HzCDL2-3 · 50 HzCDL2-4 · 50 HzCDL2-5 · 50 HzCDL2-6 · 50 HzCDL2-7 · 50 HzCDL2-9 · 50 HzCDL2-11 · 50 HzCDL2-13 · 50 HzCDL2-15 · 50 HzCDL2-18 · 50 HzCDL2-22 · 50 HzCDL2-26 · 50 HzCDL3-2 · 50 HzCDL3-3 · 50 HzCDL3-4 · 50 HzCDL3-5 · 50 HzCDL3-6 · 50 HzCDL3-7 · 50 HzCDL3-8 · 50 HzCDL3-9 · 50 HzCDL3-10 · 50 HzCDL3-11 · 50 HzCDL3-12 · 50 HzCDL3-13 · 50 HzCDL3-15 · 50 HzCDL3-17 · 50 HzCDL3-19 · 50 HzCDL3-21 · 50 HzCDL3-23 · 50 HzCDL3-25 · 50 HzCDL3-27 · 50 HzCDL3-29 · 50 HzCDL3-31 · 50 HzCDL3-33 · 50 HzCDL3-36 · 50 HzCDL4-2 · 50 HzCDL4-3 · 50 HzCDL4-4 · 50 HzCDL4-5 · 50 HzCDL4-6 · 50 HzCDL4-7 · 50 HzCDL4-8 · 50 HzCDL4-10 · 50 HzCDL4-12 · 50 HzCDL4-14 · 50 HzCDL4-16 · 50 HzCDL4-19 · 50 HzCDL4-22 · 50 HzCDL8-2/1 · 50 HzCDL8-2 · 50 HzCDL8-3 · 50 HzCDL8-4 · 50 HzCDL8-5 · 50 HzCDL8-6 · 50 HzCDL8-8 · 50 HzCDL8-10 · 50 HzCDL8-12 · 50 HzCDL8-14 · 50 HzCDL8-16 · 50 HzCDL8-18 · 50 HzCDL8-20 · 50 HzCDL10-1 · 50 HzCDL10-2 · 50 HzCDL10-3 · 50 HzCDL10-4 · 50 HzCDL10-5 · 50 HzCDL10-6 · 50 HzCDL10-7 · 50 HzCDL10-8 · 50 HzCDL10-9 · 50 HzCDL10-10 · 50 HzCDL10-12 · 50 HzCDL10-14 · 50 HzCDL10-16 · 50 HzCDL10-18 · 50 HzCDL10-20 · 50 HzCDL10-22 · 50 HzCDL12-2 · 50 HzCDL12-3 · 50 HzCDL12-4 · 50 HzCDL12-5 · 50 HzCDL12-6 · 50 HzCDL12-7 · 50 HzCDL12-8 · 50 HzCDL12-9 · 50 HzCDL12-10 · 50 HzCDL12-12 · 50 HzCDL12-14 · 50 HzCDL12-16 · 50 HzCDL12-18 · 50 HzCDL15-1 · 50 HzCDL15-2 · 50 HzCDL15-3 · 50 HzCDL15-4 · 50 HzCDL15-5 · 50 HzCDL15-6 · 50 HzCDL15-7 · 50 HzCDL15-8 · 50 HzCDL15-9 · 50 HzCDL15-10 · 50 HzCDL15-12 · 50 HzCDL15-14 · 50 HzCDL15-17 · 50 HzCDL20-1 · 50 HzCDL20-2 · 50 HzCDL20-3 · 50 HzCDL20-4 · 50 HzCDL20-5 · 50 HzCDL20-6 · 50 HzCDL20-7 · 50 HzCDL20-8 · 50 HzCDL20-10 · 50 HzCDL20-12 · 50 HzCDL20-14 · 50 HzCDL20-17 · 50 HzCDL32-10-1 · 50 HzCDL32-10 · 50 HzCDL32-20-2 · 50 HzCDL32-20 · 50 HzCDL32-30-2 · 50 HzCDL32-30 · 50 HzCDL32-40-2 · 50 HzCDL32-40 · 50 HzCDL32-50-2 · 50 HzCDL32-50 · 50 HzCDL32-60-2 · 50 HzCDL32-60 · 50 HzCDL32-70-2 · 50 HzCDL32-70 · 50 HzCDL32-80-2 · 50 HzCDL32-80 · 50 HzCDL32-90-2 · 50 HzCDL32-90 · 50 HzCDL32-100-2 · 50 HzCDL32-100 · 50 HzCDL32-110-2 · 50 HzCDL32-110 · 50 HzCDL32-120-2 · 50 HzCDL32-120 · 50 HzCDL32-130-2 · 50 HzCDL32-130 · 50 HzCDL32-140-2 · 50 HzCDL32-140 · 50 HzCDL32-150-2 · 50 HzCDL32-150 · 50 HzCDL32-160-2 · 50 HzCDL32-160 · 50 HzCDL42-10-1 · 50 HzCDL42-10 · 50 HzCDL42-20-2 · 50 HzCDL42-20 · 50 HzCDL42-30-2 · 50 HzCDL42-30 · 50 HzCDL42-40-2 · 50 HzCDL42-40 · 50 HzCDL42-50-2 · 50 HzCDL42-50 · 50 HzCDL42-60-2 · 50 HzCDL42-60 · 50 HzCDL42-70-2 · 50 HzCDL42-70 · 50 HzCDL42-80-2 · 50 HzCDL42-80 · 50 HzCDL42-90-2 · 50 HzCDL42-90 · 50 HzCDL42-100-2 · 50 HzCDL42-100 · 50 HzCDL42-110-2 · 50 HzCDL42-110 · 50 HzCDL42-120-2 · 50 HzCDL42-120 · 50 HzCDL42-130-2 · 50 HzCDL65-10-1 · 50 HzCDL65-10 · 50 HzCDL65-20-2 · 50 HzCDL65-20-1 · 50 HzCDL65-20 · 50 HzCDL65-30-2 · 50 HzCDL65-30-1 · 50 HzCDL65-30 · 50 HzCDL65-40-2 · 50 HzCDL65-40-1 · 50 HzCDL65-40 · 50 HzCDL65-50-2 · 50 HzCDL65-50-1 · 50 HzCDL65-50 · 50 HzCDL65-60-2 · 50 HzCDL65-60-1 · 50 HzCDL65-60 · 50 HzCDL65-70-2 · 50 HzCDL65-70-1 · 50 HzCDL65-70 · 50 HzCDL65-80-2 · 50 HzCDL65-80-1 · 50 HzCDL85-10-1 · 50 HzCDL85-10 · 50 HzCDL85-20-2 · 50 HzCDL85-20 · 50 HzCDL85-30-2 · 50 HzCDL85-30 · 50 HzCDL85-40-2 · 50 HzCDL85-40 · 50 HzCDL85-50-2 · 50 HzCDL85-50 · 50 HzCDL85-60-2 · 50 HzCDL85-60 · 50 HzCDL120-10 · 50 HzCDL120-20-2 · 50 HzCDL120-20-1 · 50 HzCDL120-20 · 50 HzCDL120-30-2 · 50 HzCDL120-30-1 · 50 HzCDL120-30 · 50 HzCDL120-40-2 · 50 HzCDL120-40-1 · 50 HzCDL120-40 · 50 HzCDL120-50-2 · 50 HzCDL120-50-1 · 50 HzCDL120-50 · 50 HzCDL120-60-2 · 50 HzCDL120-60-1 · 50 HzCDL120-60 · 50 HzCDL120-70-2 · 50 HzCDL120-70-1 · 50 HzCDL120-70 · 50 HzCDL150-10-1 · 50 HzCDL150-10 · 50 HzCDL150-20-2 · 50 HzCDL150-20-1 · 50 HzCDL150-20 · 50 HzCDL150-30-2 · 50 HzCDL150-30-1 · 50 HzCDL150-30 · 50 HzCDL150-40-2 · 50 HzCDL150-40-1 · 50 HzCDL150-40 · 50 HzCDL150-50-2 · 50 HzCDL150-50-1 · 50 HzCDL150-50 · 50 HzCDL150-60-2 · 50 HzCDL150-60-1 · 50 HzCDL150-60 · 50 HzCDL200-10-B · 50 HzCDL200-10-A · 50 HzCDL200-10 · 50 HzCDL200-20-2B · 50 HzCDL200-20-2A · 50 HzCDL200-20-A · 50 HzCDL200-20 · 50 HzCDL200-30-2B · 50 HzCDL200-30-A-B · 50 HzCDL200-30-2A · 50 HzCDL200-30-B · 50 HzCDL200-30-A · 50 HzCDL200-30 · 50 HzCDL200-40-2B · 50 HzCDL200-40-2A · 50 HzCDL200-40-A · 50 HzCDL200-40 · 50 HzCDL1-2 · 60 HzCDL1-3 · 60 HzCDL1-4 · 60 HzCDL1-5 · 60 HzCDL1-6 · 60 HzCDL1-7 · 60 HzCDL1-8 · 60 HzCDL1-9 · 60 HzCDL1-10 · 60 HzCDL1-11 · 60 HzCDL1-12 · 60 HzCDL1-13 · 60 HzCDL1-15 · 60 HzCDL1-17 · 60 HzCDL1-19 · 60 HzCDL1-21 · 60 HzCDL1-23 · 60 HzCDL1-25 · 60 HzCDL2-2 · 60 HzCDL2-3 · 60 HzCDL2-4 · 60 HzCDL2-5 · 60 HzCDL2-6 · 60 HzCDL2-7 · 60 HzCDL2-9 · 60 HzCDL2-11 · 60 HzCDL2-13 · 60 HzCDL2-15 · 60 HzCDL2-18 · 60 HzCDL3-2 · 60 HzCDL3-3 · 60 HzCDL3-4 · 60 HzCDL3-5 · 60 HzCDL3-6 · 60 HzCDL3-7 · 60 HzCDL3-8 · 60 HzCDL3-9 · 60 HzCDL3-10 · 60 HzCDL3-11 · 60 HzCDL3-12 · 60 HzCDL3-13 · 60 HzCDL3-15 · 60 HzCDL3-17 · 60 HzCDL3-19 · 60 HzCDL3-21 · 60 HzCDL3-23 · 60 HzCDL3-25 · 60 HzCDL4-2 · 60 HzCDL4-3 · 60 HzCDL4-4 · 60 HzCDL4-5 · 60 HzCDL4-6 · 60 HzCDL4-7 · 60 HzCDL4-8 · 60 HzCDL4-10 · 60 HzCDL4-12 · 60 HzCDL4-14 · 60 HzCDL4-16 · 60 HzCDL8-2/1 · 60 HzCDL8-2 · 60 HzCDL8-3 · 60 HzCDL8-4 · 60 HzCDL8-5 · 60 HzCDL8-6 · 60 HzCDL8-8 · 60 HzCDL8-10 · 60 HzCDL8-12 · 60 HzCDL8-14 · 60 HzCDL10-1 · 60 HzCDL10-2 · 60 HzCDL10-3 · 60 HzCDL10-4 · 60 HzCDL10-5 · 60 HzCDL10-6 · 60 HzCDL10-7 · 60 HzCDL10-8 · 60 HzCDL10-9 · 60 HzCDL10-10 · 60 HzCDL10-12 · 60 HzCDL10-14 · 60 HzCDL10-16 · 60 HzCDL10-17 · 60 HzCDL12-1 · 60 HzCDL12-2 · 60 HzCDL12-3 · 60 HzCDL12-4 · 60 HzCDL12-5 · 60 HzCDL12-6 · 60 HzCDL12-7 · 60 HzCDL12-8 · 60 HzCDL12-10 · 60 HzCDL12-12 · 60 HzCDL12-14 · 60 HzCDL15-1 · 60 HzCDL15-2 · 60 HzCDL15-3 · 60 HzCDL15-4 · 60 HzCDL15-5 · 60 HzCDL15-6 · 60 HzCDL15-7 · 60 HzCDL15-8 · 60 HzCDL15-9 · 60 HzCDL15-10 · 60 HzCDL15-12 · 60 HzCDL20-1 · 60 HzCDL20-2 · 60 HzCDL20-3 · 60 HzCDL20-4 · 60 HzCDL20-5 · 60 HzCDL20-6 · 60 HzCDL20-7 · 60 HzCDL20-8 · 60 HzCDL20-10 · 60 HzCDL32-10-1 · 60 HzCDL32-10 · 60 HzCDL32-20-2 · 60 HzCDL32-20 · 60 HzCDL32-30-2 · 60 HzCDL32-30 · 60 HzCDL32-40-2 · 60 HzCDL32-40 · 60 HzCDL32-50-2 · 60 HzCDL32-50 · 60 HzCDL32-60-2 · 60 HzCDL32-60 · 60 HzCDL32-70-2 · 60 HzCDL32-70 · 60 HzCDL32-80-2 · 60 HzCDL32-80 · 60 HzCDL32-90-2 · 60 HzCDL32-90 · 60 HzCDL32-100-2 · 60 HzCDL42-10-1 · 60 HzCDL42-10 · 60 HzCDL42-20-2 · 60 HzCDL42-20 · 60 HzCDL42-30-2 · 60 HzCDL42-30 · 60 HzCDL42-40-2 · 60 HzCDL42-40 · 60 HzCDL42-50-2 · 60 HzCDL42-50 · 60 HzCDL42-60-2 · 60 HzCDL42-60 · 60 HzCDL42-70-2 · 60 HzCDL42-70 · 60 HzCDL65-10-1 · 60 HzCDL65-10 · 60 HzCDL65-20-2 · 60 HzCDL65-20 · 60 HzCDL65-30-2 · 60 HzCDL65-30 · 60 HzCDL65-40-2 · 60 HzCDL65-40 · 60 HzCDL65-50-2 · 60 HzCDL85-10-1 · 60 HzCDL85-10 · 60 HzCDL85-20-2 · 60 HzCDL85-20-1 · 60 HzCDL85-20 · 60 HzCDL85-30-2 · 60 HzCDL85-30-1 · 60 HzCDL85-30 · 60 HzCDL85-40-2 · 60 HzCDL120-10-1 · 60 HzCDL120-10 · 60 HzCDL120-20-2 · 60 HzCDL120-20-1 · 60 HzCDL120-20 · 60 HzCDL120-30-2 · 60 HzCDL120-30-1 · 60 HzCDL120-30 · 60 HzCDL120-40-2 · 60 HzCDL120-40-1 · 60 HzCDL120-40 · 60 HzCDL120-50-2 · 60 HzCDL150-10-1 · 60 HzCDL150-10 · 60 HzCDL150-20-2 · 60 HzCDL150-20-1 · 60 HzCDL150-20 · 60 HzCDL150-30-2 · 60 HzCDL150-30-1 · 60 HzCDL150-30 · 60 HzCDL150-40-2 · 60 HzCDL200-10-B · 60 HzCDL200-10-A · 60 HzCDL200-10 · 60 HzCDL200-20-2B · 60 HzCDL200-20-2A · 60 HzCDL200-20-B · 60 HzCDL200-20-A · 60 HzCDL200-20 · 60 HzCDL200-30-2B · 60 HzCDL200-30-A-B · 60 HzCDL200-30-2A · 60 Hz

Logarithmic scales. Published catalogue data for clean water; the correct model for your duty is confirmed by our engineers.

Dimensions & weight

Net weight and the main dimensions of each model, in millimetres, from the catalogue. Open a model for the labelled dimension drawing.

ModelHzWeight (kg)B1B2B1_B2D1D2
CDL1-25023258225483148117
CDL1-35023276225501148117
CDL1-45024294225519148117
CDL1-55024312225537148117
CDL1-65025330225555148117
CDL1-75025348225573148117
CDL1-85028366225591148117
CDL1-95028384225609148117
CDL1-105029402225627148117
CDL1-115030420225645148117
CDL1-125033448245693170142
CDL1-135034466245711170142
CDL1-155035502245747170142
CDL1-175036538245783170142
CDL1-195037574245819170142
CDL1-215038610245855170142
CDL1-235038646245891170142
CDL1-255044692290982190155
CDL1-2750457282901018190155
CDL1-3050467822901072190155
CDL1-3350488362901126190155
CDL1-3650498902901180190155
CDL2-25024258225483148117
CDL2-35024276225501148117
CDL2-45025294225519148117
CDL2-55026312225537148117
CDL2-65030340245585170142
CDL2-75030358245603170142
CDL2-95033394245639170142
CDL2-115034430245675170142
CDL2-135040476290766190155
CDL2-155042512290802190155
CDL2-185046566290856190155
CDL2-225047638290928190155
CDL2-2650537203451065197165
CDL3-25023258225483148117
CDL3-35023276225501148117
CDL3-45024294225519148117
CDL3-55024312225537148117
CDL3-65025330225555148117
CDL3-75026348225573148117
CDL3-85030376245621170142
CDL3-95031394245639170142
CDL3-105032412245657170142
CDL3-115032430245675170142
CDL3-125033448245693170142
CDL3-135034466245711170142
CDL3-155035502245747170142
CDL3-175041548290838190155
CDL3-195042584290874190155
CDL3-215045620290910190155
CDL3-235046656290946190155
CDL3-255047692290982190155
CDL3-2750487282901018190155
CDL3-2950497642901054190155
CDL3-3150578103451155197165
CDL3-3350588463451191197165
CDL3-3650609003451245197165
CDL4-25022276225501148117
CDL4-35024303225528148117
CDL4-45030340245585170142
CDL4-55032367245612170142
CDL4-65033394245639170142
CDL4-75039431290721190155
CDL4-85040458290748190155
CDL4-105043512290802190155
CDL4-125044566290856190155
CDL4-145052630345975197165
CDL4-1650546843451029197165
CDL4-1950567653551120230188
CDL4-2250598463551201230188
CDL8-2/15033347245592170142
CDL8-25033347245592170142
CDL8-35035377245622170142
CDL8-45042417290707190155
CDL8-55046447290737190155
CDL8-65047477290767190155
CDL8-85055547345892197165
CDL8-105067607355962230188
CDL8-1250706673551022230188
CDL8-1450857473901137260208
CDL8-1650888073901197260208
CDL8-1850988673901257260208
CDL8-2050999273901317260208
CDL10-15040347245592170142
CDL10-25041347245592170142
CDL10-35043377245622170142
CDL10-45049417290707190155
CDL10-55053447290737190155
CDL10-65054477290767190155
CDL10-75064517345862197165
CDL10-85065547345892197165
CDL10-95066577345922197165
CDL10-105074607355962230188
CDL10-1250766673551022230188
CDL10-14501007473901137260208
CDL10-16501028073901197260208
CDL10-18501078673901257260208
CDL10-20501099273901317260208
CDL10-22501119873901377260208
CDL12-25040367290657190155
CDL12-35045397290687190155
CDL12-45055437345782197165
CDL12-55057467345812197165
CDL12-65066497355852230188
CDL12-75077547390937260208
CDL12-85078577390967260208
CDL12-95080607390997260208
CDL12-1050886373901027260208
CDL12-1250926973901087260208
CDL12-14501628455001345330255
CDL12-16501679055001405330255
CDL12-18501689655001465330255
CDL15-15033387245632170142
CDL15-25042397290687190155
CDL15-35051452345797197165
CDL15-45060497355852230188
CDL15-55062542355897230188
CDL15-65078607390997260208
CDL15-750806523901042260208
CDL15-850866973901087260208
CDL15-950887423901132260208
CDL15-10501668755001375330255
CDL15-12501709655001465330255
CDL15-145017310555001555330255
CDL15-175018611905001690330255
CDL20-15033387245632170142
CDL20-25042397290687190155
CDL20-35058452355807230188
CDL20-45074517390907260208
CDL20-55075562390952260208
CDL20-65084607390997260208
CDL20-750866523901042260208
CDL20-8501577855001285330255
CDL20-10501628755001375330255
CDL20-12501769655001465330255
CDL20-145017810555001555330255
CDL20-175020111905501740330255
CDL32-10-15063505290795190155
CDL32-105067505290795190155
CDL32-20-25076575345920197165
CDL32-205084575355930230188
CDL32-30-250996453901035260208
CDL32-3050996453901035260208
CDL32-40-2501087153901105260208
CDL32-40501087153901105260208
CDL32-50-2501878905001390330255
CDL32-50501878905001390330255
CDL32-60-2501939605001460330255
CDL32-60501939605001460330255
CDL32-70-25020510305001530330255
CDL32-705020510305001530330255
CDL32-80-25020711005001600330255
CDL32-805020711005001600330255
CDL32-90-25022611705501720330255
CDL32-905022611705501720330255
CDL32-100-25023212405501790330255
CDL32-1005023212405501790330255
CDL32-110-25027813105751885360285
CDL32-1105027813105751885360285
CDL32-120-25028213805751955360285
CDL32-1205028213805751955360285
CDL32-130-25034314506502100400310
CDL32-1305034314506502100400310
CDL32-140-25034715206502170400310
CDL32-1405034715206502170400310
CDL32-150-25035015906502240400310
CDL32-1505035015906502240400310
CDL32-160-25035616606502310400310
CDL32-1605035616606502310400310
CDL42-10-15084561345906197165
CDL42-105091561355916230188
CDL42-20-2501066413901031260208
CDL42-20501116413901031260208
CDL42-30-2501878265001326330255
CDL42-30501878265001326330255
CDL42-40-2502039065001406330255
CDL42-40502039065001406330255
CDL42-50-2502259865501536330255
CDL42-50502259865501536330255
CDL42-60-25026610665751641360285
CDL42-605026610665751641360285
CDL42-70-25032611466501796400310
CDL42-705032611466501796400310
CDL42-80-25033012266501876400310
CDL42-805033012266501876400310
CDL42-90-25033413066501956400310
CDL42-905033413066501956400310
CDL42-100-25036013866502036400310
CDL42-1005036013866502036400310
CDL42-110-25043014666852151450345
CDL42-1105043014666852151450345
CDL42-120-25043815466852231450345
CDL42-1205043815466852231450345
CDL42-130-25044416266852311450345
CDL65-10-15098561355916230188
CDL65-1050110561390951260208
CDL65-20-2501156443901034260208
CDL65-20-1501977545001254330255
CDL65-20501977545001254330255
CDL65-30-2502068365001336330255
CDL65-30-1502078365001336330255
CDL65-30502328365501386330255
CDL65-40-2502399195501469330255
CDL65-40-1502729195751494360285
CDL65-40502729195751494360285
CDL65-50-25033410016501651400310
CDL65-50-15033410016501651400310
CDL65-505033510016501651400310
CDL65-60-25034010846501734400310
CDL65-60-15036510846501734400310
CDL65-605036510846501734400310
CDL65-70-25037011666501816400310
CDL65-70-15037011666501816400310
CDL65-705043711666851851460340
CDL65-80-25044012486851933460340
CDL65-80-15044012486851933460340
CDL85-10-150109571390961260208
CDL85-1050115571390961260208
CDL85-20-2501857735001273330255
CDL85-20502027735001273330255
CDL85-30-2502258655501415330255
CDL85-30502688655751440360285
CDL85-40-2503289576501607400310
CDL85-40503289576501607400310
CDL85-50-25035110496501699400310
CDL85-505035110496501699400310
CDL85-60-25042811416851826460340
CDL85-605042811416851826460340
CDL120-10502268405001340330255
CDL120-20-25025010005001500330255
CDL120-20-15026310005501550330255
CDL120-205031010005751575360285
CDL120-30-25037511606501810400310
CDL120-30-15037511606501810400310
CDL120-305037511606501810400310
CDL120-40-25040513206501970400310
CDL120-40-15040513206501970400310
CDL120-405050113206852005460340
CDL120-50-25050914806852165460340
CDL120-50-15050914806852165460340
CDL120-505063215107602270540370
CDL120-60-25064116707602430540370
CDL120-60-15064116707602430540370
CDL120-605075716708452515580410
CDL120-70-25076618308452675580410
CDL120-70-15076618308452675580410
CDL120-705076618308452675580410
CDL150-10-1502278405001340330255
CDL150-10502408405001340330255
CDL150-20-25026310005501550330255
CDL150-20-15031110005751575360285
CDL150-205036410006501650400310
CDL150-30-25037411606501810400310
CDL150-30-15039511606501810400310
CDL150-305039511606501810400310
CDL150-40-25050213206852005460340
CDL150-40-15050213206852005460340
CDL150-405062513507602110540370
CDL150-50-25063615107602270540370
CDL150-50-15075215108452355580410
CDL150-505075215108452355580410
CDL150-60-25076216708452515580410
CDL150-60-15076216708452515580410
CDL150-605076216708452515580410
CDL200-10-B503439075501457330255
CDL200-10-A503909075751482360285
CDL200-10504439076501557400310
CDL200-20-2B5048211016501751400310
CDL200-20-2A5057811016851786460340
CDL200-20-A5071011317601891540370
CDL200-205071011317601891540370
CDL200-30-2B5084513258452170580410
CDL200-30-A-B5084513258452170580410
CDL200-30-2A5084513258452170580410
CDL200-30-B5084513258452170580410
CDL200-30-A5084513258452170580410
CDL200-305092113258952220580410
CDL200-40-2B5093815198952414580410
CDL200-40-2A501148151911402659645550
CDL200-40-A501148151911402659645550
CDL200-40501148151911402659645550
CDL1-26020258225483148117
CDL1-36020276225501148117
CDL1-46021294225519148117
CDL1-56022312225537148117
CDL1-66023330225555148117
CDL1-76026358245603170142
CDL1-86027376245621170142
CDL1-96028394245639170142
CDL1-106029412245657170142
CDL1-116029430245675170142
CDL1-126030448245693170142
CDL1-136031466245711170142
CDL1-156037512290802190155
CDL1-176038548290838190155
CDL1-196041584290874190155
CDL1-216042620290910190155
CDL1-236043656290946190155
CDL1-2560517023451047197165
CDL2-26021258225483148117
CDL2-36024286245531170142
CDL2-46025304245549170142
CDL2-56026322245567170142
CDL2-66026340245585170142
CDL2-76032368290658190155
CDL2-96036404290694190155
CDL2-116037440290730190155
CDL2-136044486345831197165
CDL2-156045522345867197165
CDL2-186054576355931230188
CDL3-26020258225483148117
CDL3-36021276225501148117
CDL3-46022294225519148117
CDL3-56025322245567170142
CDL3-66026340245585170142
CDL3-76027358245603170142
CDL3-86027376245621170142
CDL3-96033404290694190155
CDL3-106034422290712190155
CDL3-116034440290730190155
CDL3-126037458290748190155
CDL3-136038476290766190155
CDL3-156039512290802190155
CDL3-176040548290838190155
CDL3-196048594345939197165
CDL3-216049630345975197165
CDL3-2360506663451011197165
CDL3-2560587023551057230188
CDL4-26024286245531170142
CDL4-36025313245558170142
CDL4-46031350290640190155
CDL4-56034376290667190155
CDL4-66035404290694190155
CDL4-76042441345786197165
CDL4-86042468345813197165
CDL4-106051522355877230188
CDL4-126052576355931230188
CDL4-1460646503901040260208
CDL4-1660667043901094260208
CDL8-2/16032347245592170142
CDL8-26038357290647190155
CDL8-36041387290677190155
CDL8-46049427345772197165
CDL8-56050457345802197165
CDL8-66058487355842230188
CDL8-86071567390957260208
CDL8-1060806273901017260208
CDL8-1260826873901077260208
CDL8-14601538355001335330255
CDL10-16040347245592170142
CDL10-26047347290637190155
CDL10-36051377290667190155
CDL10-46060417345762197165
CDL10-56061447345792197165
CDL10-66070477355832230188
CDL10-76092517390907260208
CDL10-86093547390937260208
CDL10-96094577390967260208
CDL10-106098607390997260208
CDL10-12601006673901057260208
CDL10-14601577475001247330255
CDL10-16601598075001307330255
CDL10-17601608375001337330255
CDL12-16032357245602170142
CDL12-26041367290657190155
CDL12-36056407355762230188
CDL12-46069457390847260208
CDL12-56071487390877260208
CDL12-66077517390907260208
CDL12-76078547390937260208
CDL12-8601476655001165330255
CDL12-10601517255001225330255
CDL12-12601647855001285330255
CDL12-14601678455001345330255
CDL15-16039397290687190155
CDL15-26049407345752197165
CDL15-36058452355807230188
CDL15-46071517390907260208
CDL15-56081562390952260255
CDL15-6601506955001195330255
CDL15-7601527405001240330255
CDL15-8601537855001285330255
CDL15-9601658305001330330255
CDL15-10601678755001375330255
CDL15-12601919655501515330255
CDL20-16041397290687190155
CDL20-26056407355762230188
CDL20-36069472390862260208
CDL20-46079517390907260208
CDL20-5601486505001150330255
CDL20-6601506955001195330255
CDL20-7601627405001240330255
CDL20-8601637855001285330255
CDL20-10601878755501425330255
CDL32-10-16073505345850197165
CDL32-106081505355860230188
CDL32-20-26095575390965260208
CDL32-2060101575390965260208
CDL32-30-2601046453901035330255
CDL32-30601727505001250330255
CDL32-40-2601768205001320330255
CDL32-40601868205001320330255
CDL32-50-2601918905001390330255
CDL32-50602118905501440330255
CDL32-60-2602169605501510330255
CDL32-60602169605501510330255
CDL32-70-26025510305751605360285
CDL32-706025510305751605360285
CDL32-80-26025911005751675400310
CDL32-806031511006501750400310
CDL32-90-26031911706501820400310
CDL32-906031911706501820400310
CDL32-100-26032412406501890400310
CDL42-10-160101561390952260208
CDL42-1060106561390952260208
CDL42-20-2601787485001248330255
CDL42-20601887485001248330255
CDL42-30-2602138285501378330255
CDL42-30602138285501378330255
CDL42-40-2602539085751483360285
CDL42-40603099086501558400310
CDL42-50-2603139886501638400310
CDL42-50603139886501638400310
CDL42-60-26034010686501718400310
CDL42-606034010686501718400310
CDL42-70-26040411486851833460340
CDL42-706040411486851833460340
CDL65-10-160109561390951260208
CDL65-10601776715001171330255
CDL65-20-2601877545001254330255
CDL65-20602487545751329360285
CDL65-30-2602528365751411360285
CDL65-30603138366501486400310
CDL65-40-2603369196501569400310
CDL65-40603989196851604460340
CDL65-50-26040210016851686460340
CDL85-10-1601775715001071330255
CDL85-10601885715001071330255
CDL85-20-2602117735501323330255
CDL85-20-1602487735751348360285
CDL85-20603047736501423400310
CDL85-30-2603308656501515400310
CDL85-30-1603308656501515400310
CDL85-30603928656851550460340
CDL85-40-2603969576851642460340
CDL120-10-1602358405001340330255
CDL120-10602508405501390330255
CDL120-20-26035010006501650400310
CDL120-20-16035010006501650400310
CDL120-206038010006501650400310
CDL120-30-26044511606851845460340
CDL120-30-16044511606851845460340
CDL120-306054511907601950510370
CDL120-40-26067513508452195580410
CDL120-40-16067513508452195580410
CDL120-406067513508452195580410
CDL120-50-26069015108452355580410
CDL150-10-1602358405001340330255
CDL150-10602808405751415360285
CDL150-20-26036010006501650400310
CDL150-20-16038010006501650400310
CDL150-206043510006851685460340
CDL150-30-26054511907601950510370
CDL150-30-16066511908452035580410
CDL150-306066511908452035580410
CDL150-40-26068013508452195580410
CDL200-10-B604039076501557400310
CDL200-10-A604269076501557400310
CDL200-10604849076851592450345
CDL200-20-2B6059511317601891540370
CDL200-20-2A6071811318451976580410
CDL200-20-B6071811318451976580410
CDL200-20-A6078711318952026580410
CDL200-206078711318952026580410
CDL200-30-2B601158132511402465645550
CDL200-30-A-B601158132511402465645550
CDL200-30-2A601158132511402465645550

Spare parts for CDL / CDLF

Parts list of the series with the material of each part. To order, send the model code and the part you need.

Parts list (PDF) Request spare parts quote
No.PartMaterialStandardApplies to
Rubber partsNBR— CDL32, CDL42, CDL65, CDL85, CDL120, CDL150 +1
1BracketCast ironASTM25B CDL32, CDL42, CDL65, CDL85, CDL120, CDL150 +1
1Motor—— CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
2Pump headCast ironASTM25B CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
2Pump head (CDL)Cast ironASTM25B CDL32, CDL42, CDL65, CDL85
2Pump head (CDL)Cast ironASTM 80-55-06 CDL120, CDL150, CDL200
2Pump head (CDLF)Stainless steelAISI304 CDL32, CDL42, CDL65, CDL85, CDL120, CDL150 +1
3Seal base (CDLF)Stainless steelAISI304 CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
4DischargeStainless steelAISI304 CDL120, CDL150, CDL200
4Mechanical seal—— All sizes
5Top diffuserStainless steelAISI304 CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +7
6DiffuserStainless steelAISI304 All sizes
7Support diffuserStainless steelAISI304 All sizes
8InducerStainless steelAISI304 All sizes
8Inlet and outlet chamber (CDL)Cast ironASTM 80-55-06 CDL120, CDL150, CDL200
9Base plateCast ironASTM25B CDL32, CDL42, CDL65, CDL85
9Base plateCast ironASTM 80-55-06 CDL120, CDL150, CDL200
9Inlet and outlet chamber (CDL)Cast ironASTM25B CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +7
9Inlet and outlet chamber (CDLF)Stainless steelAISI304 All sizes
10Base plate (CDLF)Cast ironASTM25B CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
10Bottom bearingTungsten carbide— CDL32, CDL42, CDL65, CDL85
11BearingTungsten carbide— CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +6
12ImpellerStainless steelAISI304 All sizes
12ShaftStainless steelAISI316L / AISI304 / AISI431 CDL32, CDL42, CDL65, CDL85
12ShaftStainless steelAISI304 CDL120, CDL150, CDL200
13Intermediate bearingTungsten carbide— CDL32, CDL42, CDL65, CDL85
13ShaftStainless steelAISI304 / AISI316L CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
14Impeller sleeveStainless steelAISI304 CDL1, CDL2, CDL3, CDL4, CDL8, CDL10 +3
15CylinderStainless steelAISI304 All sizes
16CouplingCarbon steel— All sizes

Technical data

Liquid temperature

  • -15 to +70 °C (normal type); hot-water type -15 to +120 °C

Ambient conditions

  • Up to 40 °C and 1000 m altitude without motor derating

Motor

  • Fully enclosed fan-cooled two-pole standard motor, IP55, insulation class F

Supply voltage

  • 1 x 220-230 / 240 V
  • 3 x 200-220 / 346-380 V
  • 3 x 220-240 / 380-415 V
  • 3 x 380-415 V
  • 3 x 200-230 / 346-400 V
  • 3 x 220-255 / 380-440 V
  • 3 x 220-277 / 380-480 V

Typical applications

  • Water supply and boosting
  • Industrial liquid conveying, cooling and air-conditioning
  • Water treatment, RO, filtration
  • Irrigation, spray and drip systems

Pumped liquid

  • Thin, clean, non-flammable, non-explosive liquid without solid particles or fibres

Data basis

  • 50 Hz, 2900/2950 rpm, 20 °C clean water, kinematic viscosity 1 mm²/s; curve tolerance ISO 9906:2012 Grade 3B
  • 60 Hz, 3500/3540 rpm, 20 °C clean water, kinematic viscosity 1 mm²/s; curve tolerance ISO 9906:2012 Grade 3B

Performance values are taken from the published CNP catalogue data. Our engineers confirm the final selection for your liquid, temperature, supply and site before quoting.

Other vertical multistage pumps

CDM / CDMF

Vertical multistage centrifugal pump

  • Flow 0.5–240 m³/h
  • Head up to 312 m
  • 0.37–110 kW
View series

Need a pump or a spare part?

Send us the flow and head you need, or the model code and nameplate details of the pump you are repairing. Our team replies with a quotation.

Request a Quotation +92 345 9547419
