Mechanical Seal Failure: 8 Common Causes and How to Prevent Them

The mechanical seal is the part of a pump that fails most often. It keeps the liquid inside the pump where the rotating shaft passes through the casing. When it leaks, you lose water, damage the motor bearings and stop production. Most seal failures have a handful of causes, and most can be prevented.

1. Running dry

The seal faces are lubricated by the pumped liquid. Even a few minutes without liquid can burn and crack them. Prime the pump before starting and fit dry-run protection on automatic systems.

2. Wrong seal material for the liquid

Carbon, silicon carbide, tungsten carbide and the elastomers (NBR, EPDM, FKM) each resist different liquids and temperatures. A seal that suits clean water may swell or dissolve in a chemical. Always match the seal to the liquid and temperature.

3. Abrasive solids

Sand and scale wedge between the faces and score them. Fit a strainer or choose a harder face pair such as silicon carbide against silicon carbide.

4. Shaft misalignment and vibration

A bent shaft, worn bearings or poor alignment make the faces open and close with every turn. Check the alignment and bearing condition, and fix the cause of vibration.

5. Cavitation

Vapour bubbles collapsing inside the pump shake the whole rotating assembly and damage the seal. Make sure the available NPSH is comfortably higher than the pump requires.

6. Overheating

Heat from running against a closed valve, or from hot liquid, hardens the elastomers and cracks the faces. Never run a pump against a closed discharge for long.

7. Poor installation

Scratched faces, dirty seats, wrong spring compression or a missing O-ring cause early leaks. Fit the seal on a clean, undamaged shaft and follow the set length exactly.

8. Age

Faces and elastomers wear naturally. Plan to replace the seal at regular intervals instead of waiting for a leak, especially on critical pumps.

How to order the right seal

Give the pump model, the shaft diameter, the liquid, the temperature and the pressure. A photo of the nameplate and the old seal helps us confirm the part number the first time.

Frequently asked questions

How long does a mechanical seal last?

It depends on the duty. In clean water at normal temperature it can last for years; with solids, heat or dry running it may last only weeks.

Is a small drip from the seal normal?

A tiny amount of liquid vapour at the faces is normal during running-in. A steady drip or spray means the seal needs replacing.

Can I replace a seal myself?

Yes if you have the right tools and a clean workshop, but follow the manual. Handling the faces with oily or dirty hands shortens their life.
